3.1.11.15.2.  Choice of geometrically identical versions

Assembly without ERP number:

The top red status light at assembly level (here "hinge") signifies that this assembly does not have an ERP/PDM number.

In case there are more variants of a geometrically equal part which contain these ERP/PDM numbers (green light), the desired number can be selected in the list field at part level.

ERP/PDM - active

ERP/PDM - active

[Note]Note

As soon as an ERP/PDM number is assigned to an assembly - noticeable by the green status light (if activated) - no more changes can be made to subassemblies/single parts.

The ERP/PDM area is grayed.

ERP/PDM - grayed

ERP/PDM - grayed
