2.3.6.  NX Integration - Administration

2.3.6.1. Block [CreationOptions(is3d)]
2.3.6.1.1. Key "Poolpath"
2.3.6.1.2. Key "FileName"
2.3.6.1.3. Key "EnableMCD" - Mechatronic Concept Designer
2.3.6.1.4. Key "material"
2.3.6.1.5. Keys "feature_group_xx"
2.3.6.1.6. Keys "layer_xx" - Layer descriptions
2.3.6.1.7. Key "PhysicalPropertiesMode"
2.3.6.1.8. Key "PipingConnPoint" - NX routing function
2.3.6.1.8.1. More NX Routing options
2.3.6.2. Block [INTERFACE]
2.3.6.2.1. Key "PhysicalPropertiesPrecision" - Allow physical property precision override
2.3.6.2.2. Key "ForceCreateNew3DPreviews"
2.3.6.3. Block [UI] - Adjust menus and toolbars
2.3.6.4. Block [AttributeMapping(is3d)]
2.3.6.4.1. Key "Attr_CopyFrom_01"
2.3.6.5. Block [CadDocumentAttributes]
2.3.6.5.1. Add categories to attribute mapping
2.3.6.6. NX: Unicode support in filenames
2.3.6.7. NX: "Position Override" functionality
2.3.6.8. NX: Adjust placement dialog via macro
2.3.6.8.1. Procedure when using NX without PDM
2.3.6.8.2. Procedure when using NX with Teamcenter
2.3.6.9. NX: Macro independent placement dialog
2.3.6.10. NX: Export with topology information
2.3.6.11. Troubleshooting
2.3.6.11.1. Installation - Deinstallation
2.3.6.12. User documentation
2.3.6.13. siemenspsol.cfg
2.3.6.13.1. Reuse Library - CADENAS Library - Setting options

In the configuration file ifugnx.cfg you can find all settings for the NX integration.

The most important information is found in the single blocks and keys, in the configuration file itself.

In the following you can find more comprehensive information on some blocks and keys.

Syntax and essential concepts are found under Section 2.2, “CAD encompassing information ”.

[Note]Note

Changes at configuration files should only be performed by experienced users or CADENAS Consultants.
