3.8.1. UI Callbacks

[Hinweis]Hinweis

Keys according to the pattern "MN_XYZ_Number" do not exist anymore. As of V12 numbers have been replaced by meaningful names. In particular, please pay attention on this when updating from V11 to V12.

The following entries can be used for a configuration:

  • MN_insert3d_DisplayText (display text)

  • MN_insert3d_HelpText (help text)

  • MN_insert3d_SmallIcon (small icon)

  • MN_insert3d_LargeIcon (large icon)

  • MN_insert3d_XLargeIcon (very large icon)

  • MN_insert3d_Callback (concrete call of menu items)

  • MN_insert3d_Environment (declaration of the context in which the menu item should be displayed)

    • menu: The command is visible in the menu.

    • part: The command is visible with single parts.

    • app (application): The command is visible even without opened parts, assemblies or drawings.

    • asm (assembly): The command is visible with assemblies.

    • draw (drawing): The command is visible with drawings.

    • toolbar: The command is visible in the toolbar.

Example:

Excerpt from Insert model [Insert model]:

[UI]
MN_insert3d_DisplayText=Einfügen Modell
MN_insert3d_HelpText=Modell aus einer Bibliothek einfügen
MN_insert3d_SmallIcon=:/cadresource/icons/insert_model_3d_CAD_16x16.png
MN_insert3d_LargeIcon=:/cadresource/icons/insert_model_3d_CAD_24x24.png
MN_insert3d_XLargeIcon=:/cadresource/icons/insert_model_3d_CAD_32x32.png
MN_insert3d_Callback=?_CALLBACK_COMMAND("default_insert")
MN_insert3d_Environment=menu,part,app,asm,draw,toolbar

Details on this can be found under Abschnitt 2.2.2, „Gestaltung von PARTsolutions Schnittstellen-Menü und -Symbolleiste “.
