3.1.9.3.3.5.  Cross-section " tab page

On the Cross-section tab page, you define the cutting plane for the cross-section [Cross-section] or alternatively for the quarter section [Quarter cut].

Select the desired level in the list field and optionally the desired dislocation in the entry field.

Maxwell Render - Cross-section tab page

Maxwell Render - Cross-section tab page

Cross section

Cross section

Quarter cut

Quarter cut
